Performance Specifications

• Capacity: 1.5 Ton
• Category: DC Inverter
• Color: Ocean White
• Cooling Capacity: 22,000 BTU
• Heating Capacity: 23,000 BTU
• Cooling Running Current: 2.3 – 8.1 A
• Heating Running Current: 2.4 – 8.3 A
• Cooling Power Input: 0.52 – 1.85 kW
• Heating Power Input: 0.54 – 1.90 kW

Power Supply

• Input Power Supply: 1 Phase, 230V~, 50Hz
• Air Flow Volume: 1150 m³/h
• Refrigerant Type: R-32
• Refrigerant Charge: 1200 g

Indoor Unit

• Indoor Dimensions (L × W × H): 1015 × 325 × 225 mm
• Indoor Packing Dimensions: 1090 × 415 × 313 mm
• Indoor Net Weight: 14.4 kg
• Indoor Gross Weight: 17.7 kg

Outdoor Unit

• Outdoor Dimensions (L × W × H): 820 × 310 × 630 mm
• Outdoor Packing Dimensions: 942 × 392 × 693 mm
• Outdoor Net Weight: 37.5 kg
• Outdoor Gross Weight: 41.5 kg

Smart Features

• Cooling Mode
• Heating Mode
• Dry Mode
• Vertical Flapper Auto Swing
• Horizontal Louvers Auto Swing
• WiFi Connectivity
• Haier Smart App Support
• Self-Clean Technology
• Anti-Corrosion Protection
• Turbo Function
• ECO Mode

Warranty

• Compressor Warranty: 10 Years Real Free Warranty
• Parts Warranty: 5 Years Real Free Warranty
